    F3PU20-0NS1 YOKOGAWA 240V AC PLC Power Contrator Supply Module 50/60Hz

    Ask Lasest Price
    Brand Name : Yokogawa
    Model Number : F3PU20-0NS1
    Certification : CO
    Price : inquiry
    Payment Terms : T/T
    Supply Ability : 10 Piece per a day
    Delivery Time : 3-5 working days
    • Product Details
    • Company Profile

    F3PU20-0NS1 YOKOGAWA 240V AC PLC Power Contrator Supply Module 50/60Hz

    F3PU20-0NS1 YOKOGAWA 240V AC PLC Power Contrator Supply Module 50/60Hz


    Product Details:


    Brand NameYOKOGAWA
    ModelF3PU20-0NS1
    ConditionNew
    Gross Weight/Shipping Weight2.2 lbs / 35.2 oz / 1kg
    Packing Size6.4" x 6.4" x 4.8" (16cm x 16 cm x 12 cm)
    Country of Origin/Original CountryUnited States (USA)
    Lead TimeIn Stock
    Shipping PortXiamen
    PaymentT/T
    Sales PriceInquiry
    ColorDepend on product
    Warranty12 months
    Lead time5-8 work days
    Courier partnersDHL, UPS, TNT, FedEx and EMS


    Additional Information:


    Description
    Supply voltage100-240 V AC, single phase, 50/60 Hz
    Supply voltage fluctuation range85-264 V AC, 50/60 Hz ±3 Hz
    Power consumption85 VA
    Inrush current

    20 A max.(120 V AC,Ta=25°C)

    45 A max.(240 V AC,Ta=25°C)

    Rated output voltage5 V DC
    Rated output current4.3 A
    Insulation resistance500 V DC 5 MΩ or more between external AC terminals and FG terminal
    Dielectric strength1500 V AC for 1 minute between external AC terminals and FG terminal
    Allowable momentary power failure time20 ms
    Noise immunityNoise level: 1500 Vp-p when measured by a noise simulator having a 1 µs of noise pulse width, 1 ns of rise time, and 25 Hz to 60 Hz of repetition frequency.


    Description:


    The F3PU10-0N is used for the F3BU04-0N and F3BU06-0N base modules. The F3PU20-0N and F3PU26-0N are used for the F3BU09-0N, F3BU13-0N and F3BU16-0N base modules.



    FA-M3 base modules serve as the base for accommodating various modules. FA-M3 base modules are available in 4-, 6-, 9-, 13- and 16-slot versions. Choose an appropriate base module according to the target system requirements. There are no differences between main units and sub-units.



    FA-M3 power supply modules supply power to the FA-M3 Range-free Multi-controllers. One power supply module is required for each FA-M3 base module.



    Datasheet Link:Yokogawa F3PU20-0NS1.pdf
