    YOKOGAWA ADV551-P00 16 Channel Digital Onput Module Dual Redundant Configuration

    Ask Lasest Price
    Brand Name : Yokogawa
    Model Number : ADV551-P00
    Certification : CO
    Price : inquiry
    Payment Terms : T/T
    Supply Ability : 10 Piece per a day
    Delivery Time : 3-5 working days
    • Product Details
    • Company Profile

    YOKOGAWA ADV551-P00 16 Channel Digital Onput Module Dual Redundant Configuration

    YOKOGAWA ADV551-P00 16 Channel Digital Onput Module Dual Redundant Configuration


    Product Details:


    Brand NameYOKOGAWA
    ModelADV551-P00
    ConditionNew
    Gross Weight/Shipping Weight2.2 lbs / 35.2 oz / 1kg
    Packing Size6.4" x 6.4" x 4.8" (16cm x 16 cm x 12 cm)
    Country of Origin/Original CountryUnited States (USA)
    Lead TimeIn Stock
    Shipping PortXiamen
    PaymentT/T
    Sales PriceInquiry
    ColorDepend on product
    Warranty12 months
    Lead time5-8 work days
    Courier partnersDHL, UPS, TNT, FedEx and EMS


    Additional Information:


    Features
    Number of output channels32
    Rated applied voltage24 V DC
    External power supply rating24 V DC, 50 mA
    External power supply voltage range20.4 to 26.4 V DC
    Output ON voltage maximum value2 V DC
    Leak current maximum value when output OFF0.1 mA
    Output formatCurrent sink
    Maximum load current100 mA/channel, 26.4 V
    Withstanding voltage

    Between output signal and system: 2 kV AC,

    For 1 minute Between commons: 500 V AC,

    For 1 minute, common minus (–) side every 16-channel

    Functions

    Status output

    Pulse width output

    Time-proportioning output

    ON/OFF status output function

    One-shot pulse width output function

    Time-proportioning ON/OFF

    Output response time

    3 ms or less (for status output)

    10 ms or less (for mixed status and pulse outputs)

    Pulse width8 ms to 7200 s
    Pulse width resolution8 ms, but ON/OFF delay of maximum 1 ms is added
    Maximum current consumption700 mA (5 V DC) 60 mA (external power supply)
    External connectionPressure clamp terminal, Dedicated cable (AKB331), MIL connector cable


    Description:


    ADV551 is a digital output module.The Digital Output Modules output 32-channel or 64-channel transistor contact signals. The ADV551 can be used in dual redundant configuration.



    Description
    ModelADV551

    Digital Output Module

    (32-channel,24 V DC,Isolated)

    Suffix Codes-PWith pulse width output function/time-proportional output function
    5Without status display;with no explosion protection
    6With status display;with no explosion protection
    EWithout status display;with explosion protection
    FWith status display;with explosion protection
    0Basic type
    3With ISA Standard G3 option and temperature(-20 to 70 ℃)option
    Option Codes/D5A00

    With KS Cable Interface Adapter for 32-channel Digital

    [Model:ATD5A-00]

    /D5S00With Pressure Clamp Terminal Block for Digital Output [Model:ATD5S-00]
    /D5S10With Pressure Clamp Terminal Block for Digital Output(surge absorber) [Model:ATD5S-00]
    /D5D00With Dual Pressure Clamp Terminal Block for Digital Output [Model:ATD5D-00]
    /D5D10With Dual Pressure Clamp Terminal Block for Digital Output(surge absorber) [Model:ATD5D-10]
    /CCC01With Connector Cover for MIL Cable [Model:ACCC01]


    Datasheet Link:Yokogawa ADV551-P00.pdf
