    X20DM9324 B&R Automation Plc X20 SYSTEM Digital Mixed Module With 8 Inputs And 4 Outputs

    X20DM9324 B&R Automation Plc X20 SYSTEM Digital Mixed Module With 8 Inputs And 4 Outputs


    MATERIAL NUMBER:

    X20DM9324

    DESCRIPTION:
    • 8 digital inputs, sink connections
    • 4 digital outputs, source connections
    • 1-wire connections
    • Configurable software input filter for entire module
    • Integrated output protection

    This module is equipped with 8 inputs and 4 outputs for 1-wire connections. The inputs are designed for sink connections, the outputs for source connections.


    Short description
    I/O module8 digital inputs 24 VDC for 1-wire connections, 4 digital outputs 24 VDC for 1-wire connections
    General information
    Nominal voltage24 VDC
    B&R ID code0x20B9
    Status indicatorsI/O function per channel, operating state, module status
    Diagnostics
    Module run/errorYes, using LED status indicator and software
    OutputsYes, using LED status indicator and software (output error status)
    Power consumption
    Bus0.21 W
    Internal I/O0.5 W
    Additional power dissipation caused by actuators (resistive) [W]+0.21
    Certifications
    CEYes
    UKCAYes
    ATEXZone 2, II 3G Ex nA nC IIA T5 Gc
    IP20, Ta (see X20 user's manual)
    FTZÚ 09 ATEX 0083X
    ULcULus E115267
    Industrial control equipment
    HazLoccCSAus 244665
    Process control equipment
    for hazardous locations
    Class I, Division 2, Groups ABCD, T5
    EACYes
    KCYes
    Digital inputs
    Input characteristics per EN 61131-2Type 1
    Input voltage24 VDC -15% / +20%
    Input current at 24 VDCTyp. 3.75 mA
    Input circuitSink
    Input filter
    Hardware≤100 µs
    SoftwareDefault 1 ms, configurable between 0 and 25 ms in 0.2 ms increments
    Connection type1-wire connections
    Input resistanceTyp. 6.4 kΩ
    Switching threshold
    Low<5 VDC
    High>15 VDC
    Insulation voltage between channel and bus500 Veff
    Digital outputs
    VariantCurrent-sourcing FET
    Switching voltage24 VDC -15% / +20%
    Nominal output current0.5 A
    Total nominal current2 A
    Connection type1-wire connections
    Output circuitSource
    Output protectionThermal shutdown in the event of overcurrent or short circuit (see value "Short-circuit peak current")
    Internal freewheeling diode for switching inductive loads (see section "Switching inductive loads")
    Diagnostic statusOutput monitoring with 10 ms delay
    Leakage current when the output is switched off5 µA
    RDS(on)210 mΩ
    Peak short-circuit current<12 A
    Switch-on in the event of overload shutdown or short-circuit shutdownApprox. 10 ms (depends on the module temperature)
    Switching delay
    0 → 1<300 µs
    1 → 0<300 µs
    Switching frequency
    Resistive loadMax. 500 Hz
    Inductive loadSee section "Switching inductive loads".
    Braking voltage when switching off inductive loadsTyp. 50 VDC
    Insulation voltage between channel and bus500 Veff
    Electrical properties
    Electrical isolationChannel isolated from bus
    Channel not isolated from channel
    Operating conditions
    Mounting orientation
    HorizontalYes
    VerticalYes
    Installation elevation above sea level
    0 to 2000 mNo limitation
    >2000 mReduction of ambient temperature by 0.5°C per 100 m
    Degree of protection per EN 60529IP20
    Ambient conditions
    Temperature
    Operation
    Horizontal mounting orientation-25 to 60°C
    Vertical mounting orientation-25 to 50°C
    Derating-
    Storage-40 to 85°C
    Transport-40 to 85°C
    Relative humidity
    Operation5 to 95%, non-condensing
    Storage5 to 95%, non-condensing
    Transport5 to 95%, non-condensing
    Mechanical properties
    NoteOrder 1x terminal block X20TB12 separately.
    Order 1x bus module X20BM11 separately.
    Pitch12.5+0.2mm
