8BVI0055HWD0.000-1 B&R ACOPOSmulti Inverter Module

Ask Lasest Price
Brand Name :	B&R
Model Number :	8BVI0055HWD0.000-1
Certification :	CE
Price :	USD
Payment Terms :	T/T
Supply Ability :	10EA
Delivery Time :	3-5 working days

Add to Cart

Product Details
Company Profile

8BVI0055HWD0.000-1 B&R ACOPOSmulti Inverter Module

MATERIAL NUMBER:

8BVI0055HWD0.000-1

DESCRIPTION:

Integrated uncontrolled standstill and safe stop
Integrated connection for motor holding brake and temperature sensor
2 slots for ACOPOSmulti plug-in modules
Two fully independent power inverters in one inverter module contained in 2-axis modules

ACOPOSmulti inverter module, 7.6 A, AS, wall mounting, 2 axes

General information

B&R ID code	0x20B5
Cooling and mounting type	Wall mounting
Slots for plug-in modules	2
Certifications
CE	Yes
Functional safety	Yes
UL	cULus E225616 Power conversion equipment
EAC	Yes
KC	Yes

DC bus connection

Voltage
Nominal	750 VDC
Continuous power consumption	11.19 kW
Power dissipation depending on switching frequency
Switching frequency 5 kHz	[1.2 * IM² + 2.62 * IM + 100] W
Switching frequency 10 kHz	[2.56 * IM² + 2.8 * IM + 200] W
Switching frequency 20 kHz	[6 * IM² - 9.4 * IM + 430] W
DC bus capacitance	330 µF
Variant	ACOPOSmulti backplane

24 VDC power supply

Input voltage	25 VDC ±1.6%
Input capacitance	23.5 µF
Max. power consumption	16 W + PSLOT1 + PSLOT2 + P24 V Out + PHoldingBrake(s)
Variant	ACOPOSmulti backplane

24 VDC output

Quantity	2
Output voltage
DC bus voltage (UDC): 260 to 315 VDC	25 VDC * (UDC/315)
DC bus voltage (UDC): 315 to 800 VDC	24 VDC ±6%
Fuse protection	250 mA (slow-blow) electronic, automatic reset

Motor connection

Quantity	2
Continuous power per motor connection	5.5 kW
Continuous current per motor connection	7.6 Aeff
Reduction of continuous current depending on switching frequency
Switching frequency 5 kHz	No reduction
Switching frequency 10 kHz	0.22 A/K (starting at 43°C)
Switching frequency 20 kHz	0.15 A/K (starting at -14°C)
Reduction of continuous current depending on installation elevation
Starting at 500 m above sea level	0.76 Aeff per 1000 m
Peak current per motor connection	18.9 Aeff
Nominal switching frequency	5 kHz
Possible switching frequencies	5 / 10 / 20 kHz
Insulation stress of the connected motor per IEC TS 60034-25:2004	Limit value curve A
Protective measures
Overload protection	Yes
Short-circuit and ground fault protection	Yes
Max. output frequency	598 Hz
Variant
U, V, W, PE	Connector
Shield connection	Yes
Terminal connection cross section
Flexible and fine-stranded wires
With wire end sleeves	0.25 to 6 mm²
Approbation data
UL/C-UL-US	30 to 10 AWG
CSA	28 to 10 AWG
Terminal cable cross section dimension of shield connection	12 to 22 mm
Max. motor line length depending on switching frequency
Switching frequency 5 kHz	25 m
Switching frequency 10 kHz	25 m
Switching frequency 20 kHz	10 m

Motor holding brake connection

Quantity	2
Output voltage	24 VDC +5.8% / -0%
Continuous current	1.1 A
Max. internal resistance	0.5 Ω
Extinction potential	Approx. 30 V
Max. extinction energy per switching operation	1.5 Ws
Max. switching frequency	0.5 Hz
Protective measures
Overload and short-circuit protection	Yes
Open-circuit monitoring	Yes
Undervoltage monitoring	Yes
Response threshold for open-circuit monitoring	Approx. 0.25 A
Response threshold for undervoltage monitoring	24 VDC +0% / -4%

Enable inputs

Quantity	4 (2 per axis)
Circuit	Sink
Electrical isolation
Input - Inverter module	Yes
Input - Input	Yes
Input voltage
Nominal	24 VDC
Maximum	30 VDC
Input current at nominal voltage	Approx. 30 mA
Switching threshold
Low	<5 V
High	>15 V
Switching delay at nominal input voltage
Enable 1 → 0, PWM off	Max. 20.5 ms
Enable 0 → 1, ready for PWM	Max. 100 µs
Modulation compared to ground potential	Max. ±38 V
OSSD signal connections	Permitted Max. test pulse length: 500 µs

Trigger inputs

Quantity	2
Circuit	Sink
Electrical isolation
Input - Inverter module	Yes
Input - Input	Yes
Input voltage
Nominal	24 VDC
Maximum	30 VDC
Switching threshold
Low	<5 V
High	>15 V
Input current at nominal voltage	Approx. 10 mA
Switching delay
Rising edge	52 µs ±0.5 µs (digitally filtered)
Falling edge	53 µs ±0.5 µs (digitally filtered)
Modulation compared to ground potential	Max. ±38 V

Electrical properties

Discharge capacitance	0.2 µF

Operating conditions

Permissible mounting orientations
Hanging vertically	Yes
Horizontal, face up	Yes
Standing horizontally	No
Installation elevation above sea level
Nominal	0 to 500 m
Maximum	4000 m
Pollution degree per EN 61800-5-1	2 (non-conductive pollution)
Overvoltage category per EN 61800-5-1	III
Degree of protection per EN 60529	IP20

Ambient conditions

Temperature
Operation
Nominal	5 to 40°C
Maximum	55°C
Storage	-25 to 55°C
Transport	-25 to 70°C
Relative humidity
Operation	5 to 85%
Storage	5 to 95%
Transport	Max. 95% at 40°C

Mechanical properties

Dimensions
Width	53 mm
Height	317 mm
Depth
Wall mounting	263 mm
Weight	Approx. 2.9 kg
Module width	1
